Penguin Plasma - Air Sterilising Robot

What is the Penguin Plasma Air Sterilisation Robot?

The Penguin Plasma Air Steriliser PG01 is a robotics powered steriliser and air purifier. The PG01 is the first robot of its kind as a mobile autonomous human machine co-existence air sterilising robot.

This revolutionary device offers rapid cleaning and 99.99% sterilisation rate eliminating bacteria throughout a space.

Penguin PG01 plasma sterilisation Robot is environmentally friendly and is an exceptionally efficient automatic form of microbe control, which can effectively eradicate the reproduction of bacteria cells within its path, creating fresher, cleaner and healthier air for us all to breathe.

Main Features of the Penguin PG01 Plasma Sterilisation Robot

The Penguin PG01 maintains the intelligent technical advantages of robot autonomous navigation planning with:

3D obstacle avoidance
Human-computer interaction
Intelligent navigation

Autonomous Navigation System

The Bubble-Fish disinfection robot has a sophisticated autonomous navigation system that is extremely user friendly and can be set up within any building in minutes.

The robot is controlled in three ways:

App control.
Button panel control.
Timed automatic start and stop.

The set up will give operator management, up to date performance information and route control.

What is the Penguin Plasma Air Sterilisation Robot?

This revolutionary device offers rapid cleaning and 99.99% sterilisation rate eliminating bacteria throughout a space.

Where can the PG01 be used?

Schools
Nursing Homes
Healthcare
Offices
Gymnasiums
Retail
Hotels

Conference halls
Exhibition Centres
Function Rooms
Airports
Train Stations
Shopping Centres
Cleaning Companies

Visual Obstacle Detection & Avoidance

With industry leading SLAM technology including intelligent mobility and obstacle avoidance. The multi-sensors provide safety protection for low and higher level obstacles.

Visual Features:

3D Visual Obstacle Avoidance Camera
Laser LIDAR
Anti-collision Sensor
Control Panel
Air Volume Display
Child Safety Lock
Pause / Start
Return to Charging
Power Status
Air Volume Selection
Manual Control
Manual Disinfection

Includes Voice Prompt Broadcasting.

For manual control, the Penguin Robot can be pushed to any position to start its disinfection program.

How does the Penguin Plasma Air Sterilising Robot Work?

Within the field of indoor air disinfection and sterilisation, plasma technology has shown its unparalleled superiority.

Plasma contains a large number of active oxygen ions and high-energy free radicals as part of its components make-up.

The protein and nucleic acid substances in viruses are oxidized and denatured so eradicating most types of microorganisms.

During extensive testing after the Penguin use, observation was completed using an electron microscope. This identified that the bacterial cells and virus particles were full of holes – which were achieved with the use of electrons and ions with high kinetic energy.

Therefore, when microorganisms pass through the plasma disinfection field, high-speed particles can quickly penetrate the cell membrane to destroy DNA and proteins, causing them to rapidly lose their activity (inactivation of germ cells) until they are killed or decomposed.

This process prevents the reproduction of microorganisms. (Such as bacterial and fungal spores)

Penguin Plasma Air Sterilising Robot

The first plasma sterilising robot

Using the extremely effective and efficient Plasma Sterilisation capabilities then the Penguin has an 99.99% against

coronavirus, influenza virus, staphylococcus albus, E. coli, mould and other pathogens.

Efficient, Safe, Non-toxic & Environmentally Friendly, the perfect addition for a health building and a healthy you.

Penguin Plasma Robot Features
- Autonomous path planning and auto-navigation
- Appearance size 407mm*421mm*611mm
- Body Weight 20kg.
- Circulating Volume: 200 - 560m³/h (3 gears).
- Noise: 45 - 65dba.
- Moving Speed: 0.3m/s.
- Continuous Running: 3-hour.
- Travel Lane Width: 700mm.
- Gradeability: +/- 5º.
- Obstacle Crossing: 10mm.
- Auto Charging.
- Charging time 2-3hrs (0-80%)
- Charging Pile: Support 110V～240V wide voltage input.
- Rated output: voltage 29.4V, current 5.0A.
- Safety Protection: Visual Obstacle Avoidance.
- Working Temperature: 0 - 50ºC.
- Ozone Concentration: ≤0.16mg/m³. (Human-machine co-existence）
- The released plasma density is 1.65X1018m3- 9.1X1018m3, which is dozens of times higher than the plasma density of similar products in the market.
- Soft and hard integrated general sports chassis.
- Remote control, sterilisation data collection control closed-loop management.
- Indoor autonomous positioning, navigation and mechatronics
- Automatic solution release only when pre-programmed position is reached.
- Air Purification formaldehyde removal rate of 80%.

Book Your Demonstration

Our expert advice, site surveys and demonstrations are available to book nationwide.
